Number of Channels:8
Analog Input Range:0-10 V
Current Consumption:Max. 60 mA
Conversion Resolution:12-bit
Electrical Connection:Terminal Block
Operating Temperature:-25°C to +60°C
Mounting Style:Panel Mount
Input Resistance:2 kΩ
Output Type:Open Collector
Protection Class:IP20
The Schneider Electric TSXAEZ801 is engineered for high precision in measuring voltages ranging from 0 to 10 volts, making it ideal for a wide array of industrial automation tasks. It’s part of Schneider’s robust Modicon TSX Micro automation platform, ensuring compatibility and seamless integration with existing systems.
With its 12-bit digital conversion capability, this module delivers accurate readings that are essential for complex process control and monitoring applications. Its compact size, combined with an efficient current consumption of just 60 mA, makes it suitable for space-constrained environments without compromising performance.
Featuring a standard SUB-D 25 connector for easy installation and maintenance, the TSXAEZ801 simplifies setup processes and ensures a reliable connection. The inclusion of a 5V DC operating voltage further enhances its versatility, catering to a broad spectrum of industrial settings.
Designed with reliability at heart, the module is built for long-term operation within the temperature range of -25°C to +70°C, ensuring durability in various industrial conditions. Additionally, it complies with IEC 60947-5-1 standards, guaranteeing safety and adherence to international electrical engineering norms.
This analog input module is a testament to Schneider Electric’s commitment to innovation and efficiency in industrial automation. It’s not just about functionality; it’s about providing solutions that empower industries to achieve greater productivity and precision in their operations.
