Model Type:Redundancy Module
Manufacturer:Allen-Bradley
Model Number:1756-RM/A
Channels:2
Current Rating:Drawn: 1.16 A at 5.1 VDC, 3.4 MA at 24 VDC
Enclosure:Open Type
Rfi Suppression:Radiated: 10 V/M with 1 KHz Sine-Wave 80% AM from 80 – 2000 MHz, 10 V/M with 200 Hz 50% Pulse 100% AM at 900 MHz, 3 V/M with 1 KHz Sine-Wave 80% AM from 2000 – 2700 MHz
Display:4 Character Alpha/Numeric
Mounting:Chassis
Temperature Rating:32 – 140 °F
Power Dissipation:5.1 W
Isolation:30 V continuous
Environmental Conditions:5 – 95% non-condensing relative humidity, vibration: 2 G, shock: 30 G
This module is specifically engineered for ControlLogix systems, ensuring seamless integration and enhanced performance through its redundant architecture. It supports dual power supplies, allowing for fail-safe operation without interrupting the process.
With its robust design, the AB 1756-RM/A is capable of handling extreme temperatures, making it suitable for industrial environments where temperature fluctuations are common. Its open type enclosure facilitates easy installation and maintenance.
Equipped with advanced RFI suppression technology, this module ensures reliable communication in harsh electromagnetic environments. It utilizes state-of-the-art Ethernet/IP Bridge technology for high-speed data transfer, optimizing the performance of ControlLogix-based systems.
The inclusion of a 4-character alpha-numeric display provides quick access to system status information, enhancing operational oversight. The chassis mounting option ensures secure attachment within the industrial automation setup, maximizing uptime and reducing downtime risks.
In summary, the Allen-Bradley AB 1756-RM/A ControlLogix Redundancy Module is a sophisticated solution for enhancing the reliability and safety of industrial control systems. Its comprehensive feature set, combined with its robust build quality, makes it an indispensable component for mission-critical applications.
