Allen Bradley 1746-NI16I High Resolution Analog Input Module

Model Type:SLC500

Model Number:1746-NI16I

Manufacturer:Allen Bradley

Channels:16

Input Type:Common Mode Voltage Range: Plus/Minus 10.25 V Relative To Analog Common Terminal

Input Formats:Plus/Minus 20 MA, 4 – 20 MA, 0 – 1 MA, 0 – 20 MA

Max Voltage Input:Plus/Minus 8 V Between Any Two Signal Terminals

Current Rating:Backplane: 125 MA At 5 VDC, 75 MA At 24 VDC

Isolation:500 VAC Isolation For 1 SEC

Power Rating:Backplane: 2.425 W, Enclosure: Open Type

    The Allen Bradley 1746-NI16I module boasts a high-resolution design capable of delivering accurate and reliable data acquisition, making it an ideal choice for complex industrial control systems.

    Featuring a robust common mode voltage range of ±10.25 V relative to the analog common terminal, this module ensures compatibility with a wide array of sensors and measurement devices.

    Designed for precision, the 1746-NI16I supports various input types including 4–20 mA, 0–20 mA, 0–1 mA, and can handle maximum voltage inputs without damage up to ±8 V between any two signal terminals.

    With its 500 VAC isolation, the module provides enhanced protection against electrical noise and interference, ensuring stable performance even in harsh industrial environments.

    Equipped with a backplane current draw of 125 MA at 5 VDC and 75 MA at 24 VDC, this module efficiently manages power consumption, optimizing system performance and longevity.
