ABB 1756-OF8H HART Current/Voltage Conversion Module

Model Number:AB 1756-OF8H

Type:HART Communication Module

Input Current Range:4 to 20mA

Output Current Range:0 to 20mA

Supply Voltage:12 to 30VDC

Communication Protocol:HART

Operating Temperature:-25°C to +65°C

Humidity:0% to 95% non-condensing

Dimensions (W x H x D):50mm x 85mm x 50mm

Weight:0.2kg

    This ABB 1756-OF8H HART Current/Voltage Conversion Module is designed to facilitate the conversion of electrical signals from various sources, making it an indispensable tool for industrial automation and control systems. It ensures compatibility with a wide range of instruments, providing seamless integration for enhanced system efficiency.

    Featuring a robust design that withstands harsh industrial environments, this module operates within a broad temperature range (-20°C to +60°C), ensuring reliability in diverse applications. Its compact size (94mm x 94mm x 25.4mm) and lightweight (145g) make it easy to integrate into existing systems without compromising space or performance.

    With its support for the HART communication protocol, users can easily configure and troubleshoot the module through the use of a hand-held communicator, simplifying maintenance and enhancing operational flexibility. The ABB 1756-OF8H is compatible with various control systems, including programmable logic controllers (PLCs), ensuring seamless operation across different automation platforms.

    Engineered for precision, this module delivers accurate signal conversion with a wide operating range of 4-20mA to 0-10VDC and vice versa. This capability enables precise control over processes requiring analog inputs, such as temperature, pressure, and flow measurements, leading to improved process efficiency and product quality.

    Designed with durability and ease of use in mind, the ABB 1756-OF8H HART Current/Voltage Conversion Module is an ideal solution for industrial applications seeking reliable and efficient signal conversion capabilities. It is suitable for use in a variety of industries, including oil and gas, chemical processing, and manufacturing, where precise signal handling is critical for optimal operations.
